Koyorad V-Series All-Aluminum Racing Radiator for 2004-2009 Mazda 3 and 2007-2009 Mazdaspeed 3
The Koyorad V-Series All-Aluminum Racing Radiator is a direct-fit replacement for the first-generation (BK) 2004-2009 Mazda 3 and 2007-2009 Mazdaspeed 3. The factory radiator uses plastic end tanks that become brittle with age and heat cycles, and it was never designed for the extra heat a tuned MZR 2.3L DISI turbo engine produces. This Koyo radiator replaces it with a fully aluminum unit built for both daily driving and track days.
The V-Series core was developed specifically for engine bays where tight clearances rule out a thicker core. Koyorad uses a 25mm core for the Mazda 3 and Mazdaspeed 3, which means you get a big step up in cooling efficiency and durability without cutting, relocating parts, or modifying the engine.
Key Features
- All-aluminum construction replaces the failure-prone OEM plastic end tanks
- Slim 25mm V-Series core designed for tight engine-bay clearance
- Nocolok furnace brazed core for strong, vibration-resistant bonds between tubes, fins, and headers
- Factory-fit, direct bolt-in design with no engine modifications required
- Retains mounts for the stock fan shroud and cooling fans
- Built for both circuit and daily street use
Cooling Benefits for the Mazdaspeed 3
Turbocharged engines generate significant heat, especially with increased boost, aggressive tunes, or repeated hard pulls. Elevated coolant temperatures can trigger timing pull and reduced power. An aluminum performance radiator holds temperatures more consistently, helping your Mazdaspeed 3 make repeatable power while protecting the engine over the long term.
Fitment
- 2004-2009 Mazda 3 2.0L / 2.3L I4 (manual transmission)
- 2007-2009 Mazdaspeed 3 2.3L Turbo (manual transmission)
- Koyorad part number: KH061816
The Koyorad KH061816 is suited to replacing a cracked or leaking stock radiator, as well as to Mazdaspeed 3 builds running increased boost, an upgraded turbo, or regular track use. It bolts in using the factory mounting points and reuses the stock fans and shroud.
Koyorad Racing Limited Warranty
Every Koyorad performance radiator goes through a series of quality inspections, including three pressure tests during production. Koyorad's limited warranty applies to the original purchaser only and is not transferable to any subsequent owner.
How to Submit a Warranty Claim
Koyorad handles warranty claims through its authorized dealers and does not accept inquiries directly from end users. If a problem occurs, contact Edge Autosport, the authorized dealer you purchased from, and provide the following:
- A detailed description of the problem
- Clear digital photos of the problem
- A copy of your original invoice
- A list of all modifications to the vehicle
- Part number, date of purchase, and purchase price
- Your name, address, and daytime phone number
Once this information is received, we will contact Koyorad to begin the claims process. Photos can shorten processing time but do not replace a physical inspection.
Installation and Coolant Requirements
- Koyorad recommends installation by a professional ASE Certified mechanic.
- A complete cooling system flush and fill is required, using new coolant mixed 50/50 with distilled, de-ionized, or de-mineralized water. A coolant ratio below 50%, or water only, can cause corrosion.
- All air must be bled from the cooling system after installation. Koyorad will not accept products damaged by air left in the system.
- Inlet and outlet coolant hoses may require slight trimming to fit the thicker core.
Exclusions
This limited warranty does not cover and is void with respect to: improper installation, storage, repair, maintenance, or modification; misuse, neglect, abuse, accident, vehicle collision, impact from road debris, or physical damage; improper handling or shipping; operation contrary to furnished instructions or warnings; exposure to fire, water, excessive vibration, moisture, or extreme changes in climate or temperature; cosmetic damage; products with removed, altered, or illegible serial numbers; the cost of installation, removal, or reinstallation; and acts of God. Products sold through USA distributors are intended for use within the USA only.
Koyorad disclaims all implied warranties, including merchantability and fitness for a specific purpose, and is not liable for incidental, indirect, or consequential damages. Some states do not allow these exclusions or limitations, and you may have other rights that vary by state.
Full terms: Koyorad Racing Warranty Policy
