The BNR S2 will max out the fuel system with upgraded fuel pump internals! It really competes with the S3 but has right at a 370 WHP limitation on flow. By far the most overlooked turbo in our product range! This unit out responds the S1 and provides more under the curve performance over the S1 because of the cooler charge air from the upgraded compressor housing! This little guy packs a great punch and spools like the stock K04! We do suggest a tune with this unit because out of the box they have the heavy duty wastegate set at 15 psi!
- 2860 Gen 2 CHRA Rated at 43 lb/min
- VSR Balanced
- BNR Upgraded compressor housing
- Heavy Duty 15 psi wastegate actuator
- Heavy Duty wastegate swing valve construction
- 27mm wastegate port
- .63 a/r turbine housing
Install kit includes:
- 9 M10 1.5 staintless studs
- 9 M10 1.5 stainless nuts
- 9 M10 stainless washers
- 2 M12 copper sealing washers
- 4 M14 copper sealing washers
- 2 Oil outlet gaskets
- Stainless MLS turbine inlet gasket
- Stainless MLS turbine outlet gasket
- Firewall side extended stainless water line
*Divorced down pipes sometimes do not work with our turbocharger upgrades! If they are used, the wastegate valves sometimes doesn't function properly causing extreme high boost conditions!*
- Year:
- 2006/2007/2008/2009/2010/2011/2012/2013
- Make:
- Mazda
- Model:
- 3/6
- Submodel:
- Mazdaspeed 3/Mazdaspeed 6
